MMNeo4
90,00€
Handcrafted Humbucker Pickup IUSO MMNeo4, compatible with both active and passive 4 strings Stingray-style basses. Steel pole pieces and Neodymium disc. Thanks to the 4 conductors cable, you can connect the coils in series, parallel, or single coil configurations.
- Description
- Audio Demo
- Additional information
- Cover Dimensions
- Reviews (0)
Description
-Steel slugs
-Neodymium discs
-42awg Poly-Nylon wire
-Wax potted
-Series resistance 9-10k
-Parallel resistance 2-3k
-4 conductors cable to enable parallel, series, or separate volume use
-Upper coil with North polarity and CCW winding (black and white wires)
-Lower coil with South polarity and CCW winding (green and red wires)
-Cover with exposed pole pieces
Additional information
| Number of strings | 4 strings |
|---|---|
| Magnet | Neodimio |
| Pickup type | Humbucker |
| Resistance | 2/3k parallel, 9/10k (approx.) |
| Bobbin | Plastic |
| Cable | 4 conductors shielded |
| Winding wire | Poly nylon |
| Wire gauge | 42 awg |
| Color | Black |
| Cover | Closed |
